Description Order Number
Phase current sensor – split core
•
Ratio: 225 mV@300 A, IEC 61869-10
•
Accuracy class: 0.5/1 extension 200 %, 5P10
•
Connection cable: 2.0 m, open end
•
Internal diameter: 65 mm
6MD2320-0GA00-1AA0
Phase current sensor – closed ring core
•
Ratio: 225 mV@700 A, IEC 60044-8
•
Accuracy class: 0.5, 5P10
•
Connection cable: 3.5 m, open end
•
Internal diameter: 82 mm
•
GOST certificate
6MD2320-0JA00-0BA1
Core balance current sensor – split core
•
Ratio: 225 mV@60 A, IEC 61869-10
•
Accuracy class: 1/3
•
Connection cable: 2.0 m
•
Window diameter: 160 mm
6MD2320-0AF00-1AA0
Core balance current sensor – split core
•
Ratio: 225 mV@60 A, IEC 60044-8
•
Accuracy class: 1
•
Connection cable: 3.5 m
•
Window diameter: 120 mm
•
GOST certificate
6MD2320-0AF00-1AA1
Voltage Sensor 10 kV
•
10 kV/√3 : 3.25/√3
•
Accuracy class: 1
•
IEC 60044-7 for symmetrical T connectors with C cone for cables: Nexans
(K) 440TB/ Cellpack CTS-S/Südkabel SEHDT13 and SEHDT23
•
Voltage factor: 1.2 V
N
•
Voltage factor: 1.9 V
N
for maximum of 8 hours
6MD2320-0AA04-1AA0
Voltage Sensor 10 kV
•
10 kV/√3 : 3.25/√3
•
Accuracy class: 1
•
IEC 60044-7 for asymmetric T connectors of nkt cables type CB-24, CC-24
and Raychem RSTI-58xx/RSTI-CC-58xx
•
Voltage factor: 1.2 V
N
•
Voltage factor: 1.9 V
N
for maximum of 8 hours
6MD2320-0AA04-1AB0
Voltage Sensor 10 kV
•
10 kV/√3 : 3.25/√3
•
Accuracy class: 0.5
•
IEC 60044-7 for asymmetric T connectors of nkt cables type CB-24
•
Voltage factor: 1.2 V
N
•
Voltage factor: 1.9 V
N
for maximum of 8 hours, GOST certificate
6MD2320-0AA04-0AB1
Introduction
2.1 Overview
SICAM, Feeder Condition Monitor, Manual 17
E50417-H8940-C580-A4, Edition 03.2019
