Description Order Number
Voltage Sensor 20 kV
•
20 kV/√3 : 3.25/√3
•
Accuracy class: 0.5/1
•
IEC 61869-11 for symmetric T connectors with C cone for cables: Nexans
(K) 440TB/ Cellpack CTS-S/Südkabel SEHDT13 and SEHDT23
•
Voltage factor: 1.2 V
N
•
Voltage factor: 1.9 V
N
for maximum of 8 hours
6MD2320-0AA07-1AA0
Voltage Sensor 20 kV
•
20 kV/√3 : 3.25/√3
•
Accuracy class: 1
•
IEC 61869-11 for asymmetric T connectors of nkt cables type CB-24, CC-24
and Raychem RSTI-58xx/RSTI-CC-58xx
•
Voltage factor: 1.2 V
N
•
Voltage factor: 1.9 V
N
for maximum of 8 hours
6MD2320-0AA07-1AB0
Typical Ordering Combinations MLFB Number Use Case
LoPo
sensors
available
Neutral-
point
treat-
ment:
Solid/low-
resistant
Neutral-
point
treat-
ment:
Isolated/
compen-
sated
Conven-
tional
1 A/ 5 A
CTs avail-
able
Connect-
ing cable
SICAM FCM For resistive voltage
dividers, conventional VTs,
and 230 V.
Fault indicator with direc-
tional information and
measurements of V, I, f, P,
Q, S, cos φ, power-flow
direction, 2 digital outputs
6MD2321-1AA00
-1AA0/XX
1
1 x 1 x 1 x 1 x –
SICAM FCM For voltage detecting
systems
Fault indicator with direc-
tional information and
measurements of V, I, f, P,
Q, S, cos φ, and power-
flow direction, 2 digital
outputs
6MD2322-1AA00
-1AA0/XX
1
1 x 1 x 1 x 1 x
1 x
2
1 A adaptor 3 inputs @225mV low-
power signal
6MD2320-0AA10
-1AA0
– – – 1 x –
5 A adaptor 3 inputs @225mV low-
power signal
6MD2320-0AA20
-1AA0
– – – 1 x –
Phase-current
sensor
Depending on require-
ments
Refer to Table 2-1 – 3 x 2 x – –
2
In order to set up SICAM FCM (MLFB: 6MD2322-1AA00-1AA0/CC and above) with voltage-detection system, an appropriate
connecting cable (MLFB: 6MD2322-0AA80-0AB3) must be used.
Introduction
2.1 Overview
18 SICAM, Feeder Condition Monitor, Manual
E50417-H8940-C580-A4, Edition 03.2019
