Terminal Connections
You can connect the device terminals with a wire of cross-section ranging from 0.75 mm
2
to 2.5 mm
2
. Use the
following options to connect the terminals:
•
Spring-cage connection
Spring-cage connection is used to connect the upper row of terminals. From terminal 1 to terminal 12.
•
Screw connection
Screw connection is used to connect the bottom row of terminals. From terminal 13 to terminal 24.
The following tables show the technical details of the different connection methods.
Table 3-2 Spring-Cage Connection
Connection Elements Specifications
Connection method Spring cage
Conductor size (solid)
4.0 mm
2
Conductor size (stranded)
2.5 mm
2
Stripping length 8.0 mm
AWG (max.) 12.0
AWG (min.) 24.0
Table 3-3 Screw Connection
Connection Elements Specifications
Connection method Screw connection
Conductor size (solid)
1.0 mm
2
Conductor size (stranded)
1.0 mm
2
Stripping length 8.0 mm
AWG (max.) 16.0
AWG (min.) 26.0
Torque 0.5 Nm
Screwdriver size 3/32 inch or 2.5 mm
Hardware Components and Drawings
3.2 Terminal Diagram
24 SICAM, Feeder Condition Monitor, Manual
E50417-H8940-C580-A4, Edition 03.2019
