Digital Inputs
Number 1
External operating voltage DC 24 V to 30 V continuous signal
DC 30 V to 60 V periodic
0.5 s ON time and 4.5 s OFF time
Digital Outputs
Number 2
Type Dry contact
Maximum switching capacity 2000 VA (AC, resistive)
240 W/30 V DC (DC, resistive)
Permissible current per contact (continuous) 8 A
Permissible current per contact (switching) 8 A
Dimensions
Type of fixing Panel flush mounting
Cut-out (W x H) 92+0.8 mm x 45+0.8 mm
Overall depth 109.5 mm
Permissible switch panel thickness for installation 2 mm to 4 mm
Mounting position Horizontal
Weight ≤ 500 g
Environment
Operating temperature range
-40 °C to +70 °C
Storage temperature range -25 °C to +55 °C
Humidity range 0 % to 95 %, non-condensing
Altitude above sea level Maximum up to 2000 m
Protection Device Class
Device front
IP 40
Device rear IP 20
Power Consumption
DC 24 V/AC 230 V
0.8 W
Peak power during power on 6.0 W
NOTE
When the auxiliary power supply fails, the device is switched on with an internal battery. In this low-power
mode, the device has limited functionality.
In the low-power mode, you can reset a fault, set parameters, and view events/records. In this mode, meas-
urements, fault detection, and communication functions are not available.
Technical Data
5.1 Device Technical Data
64 SICAM, Feeder Condition Monitor, Manual
E50417-H8940-C580-A4, Edition 03.2019
