Table B-3 Bit-Type Data - Coil
Address Modbus Data Type Parameters Access
1 Coil Activate self-test mode R/W
2 Coil Reset device R/W
3 Coil Reset fault R/W
4 – Reserved for future use –
5 Coil Digital output 1 R/W
6 Coil Digital output 2 R/W
7 Coil Clear data available status R/W
8 Coil Clear event database R/W
9 Coil Initiate auto calibration R/W
10 Coil Energy counter reset R/W
11 Coil Password reset coil R/W
12 Coil Active-group switching R/W
For more information about bit-type data - discrete inputs, see B.3 Bit-Type Data.
Table B-4 Bit-Type Data - Discrete Inputs
Address Modbus Data Type Parameters Access
1 Discrete Input Status data/data available R
2 Discrete Input Self-test mode activated R
3 Discrete Input Overcurrent (I>>), high-set without direction
indication
R
4 Discrete Input Ground-fault detection (I
N
>) R
5 Discrete Input Overvoltage warning (V
max
Warning) R
6 Discrete Input Overvoltage alarm (V
max
Alarm) R
7 Discrete Input Undervoltage warning (V
min
Warning) R
8 Discrete Input Undervoltage alarm (V
min
Alarm) R
9 Discrete Input I>/I>> direction A R
10 Discrete Input I>/I>> direction B R
11 Discrete Input I
N
> direction A R
12 Discrete Input I
N
> direction B R
13 Discrete Input Forward (A) power-flow direction of I
1
R
14 Discrete Input Reverse (B) power-flow direction of I
1
R
15 Discrete Input Forward (A) power-flow direction of I
2
R
16 Discrete Input Reverse (B) power-flow direction of I
2
R
17 Discrete Input Forward (A) power-flow direction of I
3
R
18 Discrete Input Reverse (B) power-flow direction of I
3
R
19 Discrete Input Time synchronization required R
20 Discrete Input Overcurrent warning R
21 Discrete Input Overcurrent alarm R
22 Discrete Input Overcurrent stage I>, low-set without direction
indication
R
23 Discrete Input Phase-fault indication (I>/I>>) R
24 Discrete Input Phase-fault indication (I>/I>>) for at least 3 s R
25 Discrete Input Device-health status R
Modbus Registers
B.2 Implementation of the Modbus Protocol
96 SICAM, Feeder Condition Monitor, Manual
E50417-H8940-C580-A4, Edition 03.2019
