1-6
ET 200L Distributed I/O Device
EWA-4NEB 780600902-05
1.2.1 What Is the ET 200L Block I/O Device?
Figure 1-2 shows you a view of the ET 200L distributed I/O device. It con-
sists of a terminal block and an electronics block.
Electronics block
Terminal block
Figure 1-2 View of the ET 200L Distributed I/O Device
The modules incorporated in the ET 200L include:
S 24 V DC digital input and/or output modules
Features of the
ET 200L
ET 200L Modules
