Error type Error text Meaning Remedy
11011
B
27
D
Unclear error Unclear errors are those that cannot be specified in more de‐
tail
For HART modules: “Configuration Changed” signaled by the
HART field device
Different, depending
on cause of error
11100
B
28
D
Reserved
11101
B
29
D
Error 1 in actua‐
tor/sensor
Error 1 in a field device that is connected to a module
For HART modules: HART primary variable outside the limits
Correction in actuator/
sensor depending on
error message
11110
B
30
D
Error 2 in actua‐
tor/sensor
Error 2 in a field device that is connected to a module
For HART modules: At least one HART secondary variable
outside the limits
Correction in actuator/
sensor depending on
error message
11111
B
31
D
Channel/
module tempo‐
rarily unavaila‐
ble
e.g. due to calibration, firmware update, manual mode, etc. Different, depending
on the cause;
e.g., wait until the initi‐
ated function (calibra‐
tion, FW update) is fin‐
ished.
See also
Structure of slave diagnosis (Page 91)
8.3.9 H-status, only in redundant configurations
Requirement
The IM 650 supplies the H-status only when it is operated on a CPU 410 in a redundant
configuration.
Interrupt, error and system messages
8.3 S7 diagnostics
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 103
