Contents Length (bytes) Coding (hex)
SSL ID
Associated data record number
Length of the data record
Index
2
2
2
2
F1 11
00 E8
00 40
00 02
SSL ID
Associated data record number
Length of the data record
Index
2
2
2
2
F1 11
00 E9
00 40
00 03
SSL ID
Associated data record number
Length of the data record
Index
2
2
2
2
F1 11
00 EA
00 40
00 04
8-byte block information for additional data record objects
Σ: 48
2. You can find the portion of the I&M data assigned to the respective index under the
associated data record number (see table below: Structure of the I&M‑data ).
All data records containing I&M data have a length of 64 bytes.
The data records are structured in accordance with the principle shown in the table below.
Table 7-2 Basic structure of data records with I&M data
Contents Length (bytes) Coding (hex)
Header information
SSL ID 2 F1 11
Index 2 00 0x
Length of the I&M data 2 00 38
Number of blocks with I&M data 2 00 01
I&M data
Index 2 00 0x
I&M data for the respective index (see following
table)
54
Structure of the I&M data
The data structures of the I&M data correspond to the specifications of the PROFIBUS
Guideline - Order No. 3.502, Version 1.1 May 2003.
Table 7-3 Structure of the I&M data
I&M data Access Default setting Explanation
Identification data 0: Index 1 (data record 231)
MANUFACTURER_ID read (2 bytes) 2A hex (= 42 dec) The name of the manufacturer is stored here.
(42 dec = SIEMENS AG)
Functions
7.8 Identification and maintenance data (I&M data)
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 85
