10.4.1.1 Measurement types and measuring ranges
Introduction
The measurement type and range is configured at the "measuring type" parameter in
STEP 7
.
Selected type of measurement Measuring range
Voltage
V:
± 50 mV
± 500 mV
± 1 V
± 5 V
1 V to 5 V
0 V to 10 V
± 10 V
Current I 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
resistance (4-wire connection)
R-4L
6 kΩ
600 Ω
PTC
Thermal resistance
RTD-4L (linear, 4-wire connection)
(temperature measurement)
Silicon temperature sensors
Pt 100 Klima / Standard
Ni 100 Klima / Standard
Ni 1000 Klima / Standard
LG-Ni 1000 Klima / Standard
KTY83/110
KTY84/130
10.4.1.2 Parameters of the AI 8 x 13 bits
Parameter assignment
The parameters are assigned using the parameter assignment dialog of HW Config
ET 200PA SMART I/O modules
10.4 Analog input modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 161
