10.7 Dimensional drawings of the signal modules
Signal module
The following figure shows the dimension drawing of an ET 200PA SMART I/O module.
The appearance of the module can be different. The specified dimensions are always the same.
10.8 Standards and approvals
Introduction
The general technical specifications include:
● Standards and test values that the modules of the ET 200PA SMART comply with and meet.
● Test criteria according to which the ET 200PA SMART modules have been tested.
Note
Information on the nameplate
You can find the currently applicable markings and approvals on the nameplate of the
respective module.
ET 200PA SMART I/O modules
10.8 Standards and approvals
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 211
