Example configuration for time stamping of signal changes with IM 650
1
2
3
4
5
4
5
6
7
8
① Operator station (OS) for unit visualization
② Industrial Ethernet
③ Time sender (SICLOCK)
④ ET 200PA SMART Distributed I/O
⑤ Digital input module, e.g., SM 321 (6ES7321‑7TH00-0AB0)
⑥ PROFIBUS DP
⑦ AS 410-5H
Figure 7-2 Example configuration for time stamping of signal changes with IM 650
Functions
7.4 Time stamping of the input signals with IM 650
ET 200PA SMART
76 Operating Instructions, 06/2019, A5E34192013-AB
