Technical specifications
● Output voltage for transducer and cable with 22 mA
transducer current
(measurement resistance on module already taken into
account)
≥ 18 V (when UN = 24 V)
Sensor selection data
Input ranges (rated values / input resistance)
● Current
0 to 20 mA
4 to 20 mA
± 20 mA
140 Ω
140 Ω
140 Ω
Permissible input current for current input (destruction limit) 40 mA
* Cycle time = Basic conversion time per channel x Number of enabled channels
10.4.2.1 Parameters of the AI 8 x 16 Bit
Parameter assignment
The parameters are assigned using the parameter assignment dialog of HW Config
Parameters of the AI 8 x 16 Bit
The table below provides an overview of the assignable parameters and their default settings
for the AI 8 x 16 Bit.
The default settings apply when you have not assigned parameters in HW Config or you have
not changed any parameters.
Table 10-11 Parameters of the AI 8 x 16 Bit
Parameter Value range Default setting Scope
Diagnostic interrupt enable Yes / No Yes Module
Diagnostics
● Group diagnostics analog
● Wire break check
Yes / No
Yes / No
Yes
Yes
Channel
Channel
Smoothing None
Weak
Medium
Strong
None Channel
Measurement type Disabled
4WMT
*
current
2WMT
*
current
4WMT
*
current Module
ET 200PA SMART I/O modules
10.4 Analog input modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 173
