Technical specifications
● Resistance thermometer/silicon temperature sensors
Pt 100
Ni 100
Ni 1000
LG-Ni
1000
Standard / Klima
KTY83/110
KTY84/130
100 MΩ
Maximum voltage at voltage input U+ (destruction limit) max. 30 V, continuous
Maximum voltage at voltage inputs M+, M-, S- (destruction limit) max. 12 V continuous; 30 V for a duration of max. 1 s
Maximum current at current input I+ (destruction limit) 40 mA
Wiring of the signal sensors using a 40pin front connector
● for voltage measurement
● for current measurement
– as 2-wire transducer
– as 4-wire transducer
supported
supported, with external supply
supported
● for resistance measurement
with 2-wire connection
with 3-wire connection
with 4-wire connection
supported
supported
supported
Characteristics linearization programmable
● for resistance thermometers
Pt 100 Standard / Klima
Ni 100 Standard / Klima
Ni 1000 Standard / Klima
LG-Ni 1000 Standard / Klima
● Technical unit of temperature measurement
Degrees Centigrade, degrees Fahrenheit, Kelvin
ET 200PA SMART I/O modules
10.4 Analog input modules
ET 200PA SMART
160 Operating Instructions, 06/2019, A5E34192013-AB
