Properties
The DO 32 x DC 24 V/0.5 A is characterized by the following properties:
● 32 outputs, isolated in groups of 8
● Output current 0.5 A
● Rated load voltage 24 V DC
● Suitable for solenoid valves, DC contactors and signal lamps
● Group error display (SF LED)
Use of the module with high-speed counters
Note the following when using the module in combination with high-speed counters:
Note
When the 24 V supply voltage is connected via a mechanical contact, the outputs of the DO
32 x DC 24 V/0.5 A have the "1" signal for approximately 50 µs due to the circuit.
ET 200PA SMART I/O modules
10.3 Digital output modules
ET 200PA SMART
138 Operating Instructions, 06/2019, A5E34192013-AB
