Redundant use
The redundant control is possible without external protection circuit. Both signal modules must
have the same reference potential M.
0
/
9
&+[
&+[
0
/
0RGXOH
0RGXOH
Technical specifications of the DO 32 x DC 24 V/ 0.5 A
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 120
Weight Approx. 300 g
Module-specific data
Number of outputs 32
Cable length
● Unshielded
● Shielded
Max. 600 m
Max. 1000 m
Voltages, currents, potentials
Rated load voltage L+ 24 V DC
ET 200PA SMART I/O modules
10.3 Digital output modules
ET 200PA SMART
140 Operating Instructions, 06/2019, A5E34192013-AB
