Technical specifications
● Output voltage
● Output current
● Temperature error (relative to output range)
● Linearity error (relative to output range)
● Repeat accuracy (in transient state at 25 °C, relative to output
range)
● Output ripple; bandwidth 0 kHz to 50 kHz (relative to output range)
± 0.4%
± 0.5%
± 0.002 %/K
+ 0.05%
± 0.05%
± 0.05%
Status, interrupts, diagnostics
Interrupts
● Diagnostic interrupt
Configurable
Diagnostic functions
● Group error display
● Diagnostic information can be read
Configurable
Red LED (SF)
Possible
Actuator selection data
Output ranges (rated values)
● Voltage (as of product version 3)
± 10 V
0 V to 10 V
1 V to 5 V
● Current
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
Load resistance (in the nominal range of the output)
● for voltage outputs (as of product version 3)
– Capacitive load
min. 1 kΩ
max. 1 µF
● At current outputs
– At U
CM
< 1 V
– With inductive load
Max. 500 Ω
Max. 600 Ω
max. 10 mH
Voltage output
● Short-circuit protection
● Short-circuit current
Yes
max. 25 mA
Current output
● Noload voltage
Max. 18 V
● Destruction limit against external voltages/currents
● Voltage at outputs to M
ANA
● Current
Max. 18 V continuous; 75 V for max. 1 s
(duty factor 1:20)
Max. 50 mA DC
Connection of the actuators
● for voltage output
4-wire connection
● for current output
2-wire connection
using a 40-pin front connector
(as of FD 3) possible
ET 200PA SMART I/O modules
10.5 Analog output modules
ET 200PA SMART
Operating Instructions, 06/2019, A5E34192013-AB 207
