Siemens SIMATIC Ident Function Manual

Setting parameters for blocks
3.5 Programming the Ident profile
Ident profile and Ident blocks, standard function for Ident systems
Function Manual, 10/2018, C79000-G8976-C387-04
97
Byte
Value
RFID system
Meaning
Byte 16
field_on_
time
RF200
Transponder type
0x01 Any ISO transponder
RF300 Selection of the transponder types used
With the value "0x01"/"0x31" (ISO 15693 general), the readers of the 2nd genera-
tion always use the ISO commands with which the highest performance can be
achieved for the particular transponder. With readers of the 1st generation, the
value "0x01" activates the general ISO mode with rudimentary ISO commands.
With this setting, the performance is generally limited, but the operation is basically
guaranteed with each ISO-compatible transponder.
The transponder chip types of the transponders specified in the system manual
"SIMATIC RF300" in the section "RF300 transponders" support these commands.
The following values can be set:
Value Transponder
type
Description
0x00 RF300
(RF3xxT)
For all transponders of the type "RF3xxT"
0x01 ISO 15693
general
Any ISO transponder
Activation of the general ISO mode with rudimentary
ISO commands. With this setting, operation is basically
guaranteed with every ISO-compatible transponder.
0x03 ISO 15693
(Infineon, MDS
D3xx)
e.g. MDS D324, D339
0x04 ISO 15693
(Fujitsu - 2 kB,
MDS D4xx)
e.g. MDS D421, D422, D423, D424, D425, D426,
D428, D460
0x05 ISO 15693
(NXP, MDS
D1xx)
e.g. MDS D100, D124, D126, D139, D150, D165
0x06 ISO 15693
(TI, MDS D2xx)
e.g. MDS D200
0x07 ISO 15693
(STM, MDS
D261)
e.g. MDS D261
0x08
1)
ISO 15693
(Fujitsu - 8 kB,
MDS D5xx)
e.g. MDS D521, D522, D524, D525, D528
0x10
1)
RF300
(RF3xxT)
For all transponders of the type "RF3xxT"
0x20
1)
ISO 14443
(MOBY E,
E6xx)
e.g. MDS E600, E611, E623, E624
0x31
1)
General mode
(ISO, RF300,
MOBY E)
Activation of the so-called "General mode" for pro-
cessing the transponder types RF300, ISO 15693 and
ISO 14443. With this setting, operation is basically
guaranteed with every compatible transponder. If ISO
mode and RF300 mode are activated a transponder
can be processed up to maximum address "8192" even
if the RF300 transponder has a memory of 64 kB.
