Siemens SIMATIC IPC277E User Manual

Technical specifications
8.4 Technical specifications
SIMATIC IPC277E
Operating Instructions, 11/2019, A5E35783335-AE
107
Interfaces
COM
• RS 232
1
, max. 115 Kbps, D-sub connector, 9-pin
• RS485
1 2
/RS422
1
(optional), max. 115 kbps, D-sub connector,
9-pin
USB
• 7" and 9": 2 × USB 2.0, 1 × USB 3.0
maximum 6 Watt USB load
• 12", 15" and 19": 3 × USB 2.0, 1 × USB 3.0
maximum 6 Watt USB load
3 × USB 2.0, maximum of 2 can be operated in high-current
mode at the same time
• 15"/19": 1 x front USB 2.0 high current
LAN interface X1 P1, RJ45
3
Intel LAN Controller Springville i210
10, 100, 1000 Mbps, teaming
4
LAN interface X2 P1, RJ45
3
Intel LAN Controller Springville i210
10, 100, 1000 Mbps, teaming
4
Keyboard, mouse
Connection via USB port
1
In the BIOS setup, you can configure support for RS232 or RS422/RS485 for each COM port.
Available parameters:
- Autodirection
- Onboard termination
- Half-duplex or Full-duplex
2
Termination can be set in BIOS.
3
For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by the
operating system can differ.
4
Teaming can be set and initiated in the configuration interface. Jumbo frames, e.g. for the camera
application, are not supported in teaming operation.
No teaming is possible in combination with Windows 10.
