Technical specifications
8.4 Technical specifications
SIMATIC IPC277E
Operating Instructions, 11/2019, A5E35783335-AE
111
8.4.5 Power supply 12", 15" and 19" device
Maximum permitted current consumption at the USB ports
Auxiliary components
Maximum permitted power consumption
Max. total power
+5 V
USB device
3.0
High current
900 mA
6 W (for all USB devices)
Low current
100 mA
USB Device
2.0
High current 500 mA
Typical power consumption
Power consumption (at a rated voltage of 24 V)
12"
15"
19"
Basic device with Intel Celeron N2807
24 W
36 W
36 W
Basic device with Intel Celeron N2930
24 W
36 W
36 W
SSD
2 W
2 W
2 W
Maximum USB extension
Max. 6 W
Max. 6 W
Max. 6 W
USB port, front
-
Max. 2.5 W
Max. 2.5 W
DC power supply
Input voltage
24 VDC (19.2 to 28.8 VDC)
Power consumption
1
Max. 72 W
Power failure buffering Hold-up time > 15 ms
(DC_FAIL becomes active after > 5 ms)
Maximum continuous output power
1
80 W
1
The power specifications apply to the power supply component, not to the device.
Note
Differences in power supply performance
A power supply with a maximum continuous output power of 60
W or 80 W can be installed
on the 12", 15" and 19" devices. However, these differences in performance have no
influence on the other properties of the device.
Note
Inrush current
The device needs an inrush current of at least 4.5
A for 25 ms.
The peak value of the
inrush current depends on the input voltage and the impedance of the
24 V source; peak currents in excess of 4.5 A are possible. This will not have a negative
impact on device functionality.
