Installing and connecting the device
3.2 Installing the device
SIMATIC IPC277E
Operating Instructions, 11/2019, A5E35783335-AE
39
3.2 Installing the device
3.2.1 Installation guidelines
The installer of the plant is responsible for proper installation of the device.
Dangerous voltage in control cabinet
A high voltage may be present in the switchgear cabinet and could cause a dangerous
electric shock.
It may result in death or serious physical injury.
Isolate the power supply to the control cabinet before opening it. Ensure that the power to
the control cabinet cannot be turned on accidentally.
If you install the device in an unapproved mounting position or if you do not observe the
ambient conditions, the device can overheat.
Overheating can cause a fire. Proper functioning of the device is no longer guaranteed.
Before you install the device, note the following general installation information.
Note
In the standard installation position, the device meets the requirements for fire protection
enclosures in accordance with EN 61010
-2-201. It can therefore be installed without an
additional fire protection covering.
● Install the device only in one of the permitted mounting positions.
● For installation in control cabinets, note the SIMATIC setup guidelines as well as the
relevant DIN/VDE requirements or the country-specific regulations.
● Provide adequate volume in the control cabinet for air circulation and heat transport.
Keep at least 5 cm distance between the device and control cabinet.
● The ventilation slots of the device may not be covered or obstructed.
● The minimum distance between the device and the cabinet is 5 cm at the air output end.
● Ensure there is enough free space in the control cabinet to allow the cover to be
removed.
● Equip the control cabinet with struts for stabilizing the mounting cut-out. Install struts
where necessary.
