Installing and connecting the device
3.1 Preparing for installation
SIMATIC IPC277E
Operating Instructions, 11/2019, A5E35783335-AE
35
3.1.3 Permitted mounting positions
The device may be mounted in the following positions:
● Standard position: Vertical installation in horizontal format
For vertical installation in horizontal format, the following ambient temperatures are
permitted:
Maximum ambient temperature at the device
Comment
7", 9" and 12"
15"
19"
50 °C 50 °C 45 °C The device enclosure fulfills the requirement
of a fire protection enclosure.
● Inclined installation in horizontal format with a vertical inclination of maximum ±45 °
