Technical specifications
8.4 Technical specifications
SIMATIC IPC277E
112 Operating Instructions, 11/2019, A5E35783335-AE
8.4.6 Delivery state of the pre-installed software
8.4.6.1 Boot mode
Note
Setting Boot mode
We recommend that you restore the target system in the Boot mode that was set in the
delivery state.
Windows 10: UEFI Mode (UEFI = Unified Extensible Firmware Interface)
Windows 7: MBR Mode (MBR = Master boot record)
Windows Embedded Standard 7E: MBR Mode
Windows Embedded Standard 7P: MBR Mode
8.4.6.2 Partitions in Windows Embedded Standard 7
Partitioning of the SIMATIC IPC CFast card
The SIMATIC IPC CFast card for Windows Embedded Standard 7 comes configured with
the following default partitions:
Partition
Name
Size of the card
File system
8 GB
16 GB
First
SYSTEM
7 GB
12 GB
NTFS (compressed)
Second
DATA
Remainder
Remainder
NTFS (compressed)
* Due to partitioning/formatting, the actual CFast capacity does not correspond to the
memory size specified on the SIMATIC IPC CFast card.
Partitioning the hard disk or the SSD drive
The following partitions are configured in the delivery state of the data storage medium with
Windows Embedded Standard 7:
Partition
Name
Size of data medium
File system
>64 GB
>100 GB
Primary
System
50 GB
100 GB
NTFS not compressed
Second
Data
Remainder
Remainder
NTFS not compressed
