Siemens SIMATIC IPC277E

Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC277E
56 Operating Instructions, 11/2019, A5E35783335-AE
Procedure
Switch off the 24 V DC power
supp
ly.
Connect the wires of the power
supply.
Connect the connection terminal
at the marked position.
Secure the connection terminal
with the marked screws.
