Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC277E
Operating Instructions, 11/2019, A5E35783335-AE
59
Procedure for multi-touch device
You can install a strain relief (included in scope of delivery) on the rear panel using the 4
marked screws.
Secure the connecting
cables with cable ties at a
suitable point in the marked
area.
