Siemens SIMATIC IPC327G

Technical specifications
7.4 Technical data
SIMATIC IPC327G
60 Operating Instructions, 09/2021, A5E51366275-AA
Noise immunity on signal lines
Burst:
• ± 1 kV (5 kHz /100 kHz) in accordance with IEC 61000-4-4;
Length of signal port extension cable < 30 m;
• ± 2 kV (5 kHz /100 kHz) in accordance with IEC 61000-4-4;
Length of signal port extension cable ≥ 30 m
Surge:
• ± 1 kV line-to-line; ± 2 kV line-to-earth in accordance with IEC
61000-4-5; Length of signal port extension cable ≥ 30 m
Immunity to discharges of static
electricity
± 4 kV contact discharge in accordance with IEC 61000-4-2
± 8 kV air discharge in accordance with IEC 61000-4-2
Immunity to RF interference
Radiation Immunity (according to IEC 61000-6-2)
• 80 MHz to 1GHz
10 V/m, 80 % AM (1 kHz)
• 1.4 GHz to 2 GHz
3 V/m, 80 % AM (1 kHz)
• 2 GHz to 26 GHz
1 V/m, 80 % AM (1 kHz)
Conducted Immunity (according to IEC 61000-4-6)
• 10 kHz to 80MHz: 10 V, 80% AM (1kHz)
Conducted Emission (Low voltage
DC mains port), in accordance with
IEC 61000-6-4 + A1
• 0.15 to 0.5 MHz / 79 dB (μV) Q, 66 dB (μV) M
• 0.5 to 30 MHz / 73 dB (μV) Q, 60 dB (μV) M
Conducted Emission (Telecommu-
nications/Network Port),
in accordance with IEC 61000-6-4
+ A1
0.15 to 0.5 MHz:
97 dB(μV) to 87 dB(μV) Q
74 dB(μV) to 74 dB(μV) M
0.5 MHz to 30 MHz:
87 dB(μV) Q / 74 dB(μV) M
Main circuit board
Processor
• Intel Atom® x6413E: Quad Core, 1.5 GHz, burst frequency
3.0 GHz, 9W TDP
Main memory
Memory expansion up to 16 GB with the following memory
modules:
• 4G DDR4 SDRAM
• 8G DDR4 SDRAM
• 16G DDR4 SDRAM
The max speed of memory is up to 3200 MT/s.
The memory module supports IBECC function, and its default
value in BIOS is "Disable".
