Configuring with Web Based Management
5.5 "System" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
Configuration Manual, 11/2014, C79000-G8976-C350-03
113
●
"Agent VLAN ID" drop-down list
Select the VLAN ID from the drop-down list. The drop-down list is available only if the
"Base Bridge Mode" parameter is set to "802.1 Q VLAN Bridge". You can configure the
parameter in "Layer 2 > VLAN > General". You can only select VLANs that have already
been configured.
Note
Changing the Agent VLAN ID
If the configuration PC is connected directly to the device via Ethernet and you
change
the Agent VLAN ID, the device is no longer reachable via Ethernet following the change.
●
Shows the MAC address of the device. The MAC address is linked to the hardware and
cannot be modified.
1. In the input boxes, enter the IP address, subnet mask and the default gateway.
2. Select the assigned VLAN ID from the "Agent VLAN ID" drop-down list. If the drop-down
list cannot be enabled, check whether the "Base Bridge Mode" parameter is set to "802.1
Q VLAN Bridge". You can configure the parameter in "Layer 2 > VLAN > General".
3. Click the "Set Values" button.
