Configuring with Web Based Management
5.4 "Information" menu
SCALANCE W760/W720 to IEEE 802.11n Web Based Management
90 Configuration Manual, 11/2014, C79000-G8976-C350-03
The table has the following columns:
●
Radio
Shows the available WLAN interfaces in this column.
●
Type
Shows the mode of the WLAN interface.
●
SSID
Shows the SSID of the access point.
●
BSSID
Shows the MAC address of the access point.
●
System Name
displays the system name of the device. The entry depends on the access point. Not all
access points support this parameter.
●
Channel
Shows the channel over which the client communicates with the access point.
●
Signal Strength [dBm]
Shows the signal strength of the client in dBm.
●
Signal Strength [%]
Shows the signal strength of the client as a percentage.
●
Age [s]
Shows the time that has elapsed since the last access point activity.
●
Security
Shows which authentication method is used.
If the authentication method "Open System + Encryption" or "Shared Key" is used,
"Encrypted (WEP/AES)" is displayed for both authentication methods.
●
WLAN Mode
Shows the transmission standard. If DFS is activated, the transmission standard
"802.11h" is not shown additionally but only the configured transmission standard
"802.11a" or "802.11n".
5.4.11.5
Overview Client
Overview of the configuration
Note
This page is only available for clients or access points in client mode.
The page shows an overview of the existing clients and their configuration.
