Siemens SIMATIC NET SCALANCE W780 Series User Manual

Configuring with Web Based Management
6.3 "Wizard" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
114 Configuration Manual, 08/2018, C79000-G8976-C267-13
6.3.1.12
Dot1x RADIUS Server Settings
Introduction
On this Basic Wizard page, you configure the settings for the primary RADIUS Server.
After completing the Basic Wizard, you can configure a backup server and other settings, for
example the number of logon attempts with "Security> WLAN > AP Radius Authenticator.
Note
This page is available only i
n access point mode.
Description
This table contains the following columns:
●
Server Role
Shows the role of the server.
●
Server IP Address
Enter the IP address of the RADIUS server. The use of the computer name (name
resolution using DNS) instead of the IP address is not supported.
●
Server Port
Enter the port of the RADIUS server.
●
Shared Secret
Enter the password of the RADIUS server.
●
Shared Secret Conf
Enter the password again in this input box.

Siemens SIMATIC NET SCALANCE W780 Series Specifications

General

IP Rating	IP30
Product Type	Wireless Access Point
Frequency Bands	2.4 GHz, 5 GHz
Wireless Standard	IEEE 802.11a/b/g/n/ac
Data Rate	Up to 1.3 Gbps
Operating Temperature	-20°C to +60°C
Power Supply	24 V DC
Mounting Type	DIN rail, wall
Security	Firewall
Management	Web-based, SNMP, CLI
Weight	0.6 kg
