Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
290 Configuration Manual, 08/2018, C79000-G8976-C267-13
1. Select the required channel from the "Channel" drop-down list.
2. Enter network name in the "SSID" input box for the corresponding WLAN interface and
port.
3. For the relevant WLAN interface and the port, select the "Enabled" check box.
4. Click the "Set Values" button.
In normal operation, the access point is used as an interface to a network and communicates
with clients. There are, however, situations in which several access points need to
communicate with each other, for example to extend wireless coverage or to set up a
wireless backbone. This mode is possible with WDS (Wireless Distributed System).
Note
This WBM page is only available in access point mode.
