Siemens SIMATIC NET SCALANCE W780 Series User Manual

Configuring with Web Based Management
6.4 "Information" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
152 Configuration Manual, 08/2018, C79000-G8976-C267-13
Table 2 has the following columns:
●
Radio
Shows the available WLAN interfaces in this column.
●
Port
Shows the port of the virtual access point.
●
MAC Address
Shows the MAC address of the virtual access point.
●
SSID
Shows the SSID.
●
Security
Shows which authentication method is used.
– If the authentication method "Open System + Encryption" or "Shared Key" is used, the
"Encrypted (WEP/AES)" is displayed for both authentication methods.
– If iPCF, iPCF-HT or iPCF-MC mode is enabled on a WLAN interface, the following is
displayed depending on the encryption status:
iPCF Encrypted (AES): Encryption is enabled.
iPCF authentication: Encryption is disabled.
●
State
Shows the status of the WLAN interface.
– enabled
The WLAN interface is enabled.
– disabled
The WLAN interface is disabled.
6.4.14.2
Client list
Logged-on clients
The WBM page shows the clients logged on to the access point as well as additional
information, for example status, signal strength, MAC address.
Note
This WBM page is only available in access point mode.

Siemens SIMATIC NET SCALANCE W780 Series Specifications

General

IP Rating	IP30
Product Type	Wireless Access Point
Frequency Bands	2.4 GHz, 5 GHz
Wireless Standard	IEEE 802.11a/b/g/n/ac
Data Rate	Up to 1.3 Gbps
Operating Temperature	-20°C to +60°C
Power Supply	24 V DC
Mounting Type	DIN rail, wall
Security	Firewall
Management	Web-based, SNMP, CLI
Weight	0.6 kg
