Configuring with Web Based Management
6.5 "System" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
184 Configuration Manual, 08/2018, C79000-G8976-C267-13
The system name is also displayed in the CLI input prompt. The number of characters in
the CLI input prompt is limited. The system name is truncated after 16 characters.
●
You can enter the name of a contact person responsible for managing the device. A
maximum of 255 characters are possible.
●
You can enter the location where the device is installed. The entered installation location
is displayed in the selection area. A maximum of 255 characters are possible.
Note
The ASCII code 0x20 to 0x7e is
used in the input boxes.
1. Enter the contact person responsible for the device in the "System Contact" input box.
2. Enter the identifier for the location at which the device is installed in the "System
Location" input box.
3. Enter the name of the device in the "System Name" input box.
4. Click the "Set Values" button.
Coordinates
Information on geographic coordinates
In the "Geographic Coordinates" window, you can enter information on the geographic
coordinates. The parameters of the geographic coordinates (latitude, longitude and the
height above the ellipsoid according to WGS84) are entered directly in the input boxes of the
"Geographic Coordinates" window.
Use suitable maps for obtaining the geographic coordinates of the device.
The geographic coordinates can also be obtained using a GPS receiver. The geographic
coordinates of these devices are normally displayed directly and only need to be entered in
the input boxes of this page.
