Configuring with Web Based Management
6.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
267
●
Link
Shows the connection status to the network. With the connection status, the following is
possible:
– up
The port has a valid link to the network, a link integrity signal is being received.
– down
The link is down, for example because the connected device is turned off.
●
Mode
Shows the transmission speed and the transmission method of the port.
●
MTU (Maximum Transmission Unit)
Shows the packet size.
●
Negotiation
Shows whether the automatic configuration is enabled or disabled.
●
MAC Address
Shows the MAC address of the port.
6.6.1.2
Configuration
Configuring ports
With this page, you configure the Ethernet ports of the device.
Note
SCALANCE W786-2 SFP
The two SFP ports of the SCALANCE W786
-2 SFP cannot be assigned parameters or
diagnosed individually.
