Configuring with Web Based Management
6.5 "System" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
224 Configuration Manual, 08/2018, C79000-G8976-C267-13
Description
The page contains the following boxes:
●
Pool ID
From the drop-down list, select the required IPv4 address band.
●
Hardware Type
Select the method according to which a client is identified.
– Ethernet MAC
The client is identified by its MAC address.
– Client ID
The client is identified by a freely defined DHCP client ID. The client ID can be up to a
maximum of 254 characters long.
●
Value
Enter the MAC address or the client ID and click the "Create" button to create the entry.
Note
A maximum of 20 entries are possible.
The table has the following columns:
●
Select
Select the check box in the row to be deleted.
●
Pool ID
● Shows the number of the IPv4 address band.
Note
Only Pool ID = 1 is supported.
●
Hardware Type
Shows whether the client is identified by its MAC address or the client ID.
●
Value
Shows the MAC address to which the IPv4 address is assigned.
●
IP Address
Specify the IPv4 address. The IPv4 address must match the subnet of the IPv4 address
band.
