Configuring with Web Based Management
6.5 "System" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
252 Configuration Manual, 08/2018, C79000-G8976-C267-13
In addition, the corresponding error message is entered in the result log table. The content of
the event log table is displayed in "Information > Log Tables > Event Log".
Note
This WBM page is not available on the SCALANCE W786
-2 SFP.
1. Click the check box in front of the line name you want to monitor to enable or disable the
monitoring function.
2. Click the "Set Values" button.
Monitoring of the redundant power supply by PROFINET
With the following devices, you can also configure which power supply will be monitored by
PROFINET:
● SCALANCE W788-x (RJ-45 variants)
● SCALANCE W748-1 RJ-45
● SCALANCE W774-1 (RJ-45 and M12 variant)
● SCALANCE W734-1 RJ-45
