Siemens SIMATIC NET SCALANCE W780 Series User Manual

Configuring with Web Based Management
6.9 "Security" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
372 Configuration Manual, 08/2018, C79000-G8976-C267-13
Procedure
1. Select the required security settings. The settings that are possible depend on the
"Authentication Type" you have selected.
Authentication Type
Encryption
Cipher
Encryption key source
Open System
disabled
--
--
Open System Enabled WEP Default Key
Shared Key
Enabled
WEP
Default Key
WPA (RADIUS)
Enabled
Auto/TKIP/AES
RADIUS Server
WPA-PSK
Enabled
Auto/TKIP/AES
WPA(2) Pass Phrase
WPA2 (RADIUS)
Enabled
Auto/TKIP/AES
RADIUS Server
WPA2-PSK
Enabled
Auto/TKIP/AES
WPA(2) Pass Phrase
WPA/WPA2-AutoPSK
Enabled
Auto/TKIP/AES
WPA(2) Pass Phrase
WPA/WPA2-Auto
(RADIUS)
Enabled Auto/TKIP/AES RADIUS Server
iPCF authentication
1)
enabled
AES
Default Key (128-bit)
1)
only when iPCF with iPCF-HT or with iPCF-MC is selected: Preset authentication with optional
encryption
2. Click the "Set Values" button.

Siemens SIMATIC NET SCALANCE W780 Series Specifications

General

IP Rating	IP30
Product Type	Wireless Access Point
Frequency Bands	2.4 GHz, 5 GHz
Wireless Standard	IEEE 802.11a/b/g/n/ac
Data Rate	Up to 1.3 Gbps
Operating Temperature	-20°C to +60°C
Power Supply	24 V DC
Mounting Type	DIN rail, wall
Security	Firewall
Management	Web-based, SNMP, CLI
Weight	0.6 kg
