Siemens SIMATIC NET SCALANCE W780 Series User Manual

Configuring with Web Based Management
6.9 "Security" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
377
Description
Table 1 has the following columns:
●
Column 1
Shows that the settings are valid for all ports of table 2.
●
within own VAP / with other VAPs / with Ethernet / Client Limiter
In the drop-down list, select the setting for all ports. If "No Change" is selected, the entry
in table 2 remains unchanged.
●
Copy to Table
If you click the button, the setting is adopted for all ports of table 2.
Table 2 has the following columns:
●
Radio
Shows the available WLAN interfaces.
●
Port
Shows the VAP interface.
●
within own VAP
– Enabled
Clients logged on to the same VAP interface of an access point can communicate with
each other.
– Disabled
Option is disabled.
●
with other VAPs
– Enabled
Clients logged on to different VAP interfaces of an access point can communicate with
each other.
Note
For an access point, "with other VAPs" needs to be enabled on all WLAN interfaces or
on all VAP interfaces to allow communication between clients logged on at different
VAP interfaces of the access point.
– Disabled
Option is disabled.
Note
"within own VAP" or "with other VAPs" function disabled
If the "within own VAP" or "with other VAPs" function is disabled the various WLAN clients
can no longer see each other. This means that Address Collision Detection (ACD) also
no longer works reliably.
