Siemens SIMATIC NET SCALANCE W780 Series

Configuring with Web Based Management
6.9 "Security" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
386 Configuration Manual, 08/2018, C79000-G8976-C267-13
The table has the following columns:
●
Rule Order
Shows the order of the ACL rules.
●
Rule Number
Shows the number of the ACL rule.
●
Source MAC address
Shows the MAC address of the source.
●
Dest. MAC Address
Shows the MAC address of the destination.
●
Action
Shows the action.
– Forward
If the frame complies with the ACL rule, the frame is forwarded.
– Discard
If the frame complies with the ACL rule, the frame is not forwarded.
Configuration procedure
Follow the steps below to assign an ACL rule to an interface:
1. Select the interface from the "Interface" drop-down list.
2. Select the ACL rule in the "Add Rule" drop-down list.
3. Click the "Add" button. A new entry is generated in the table.
Follow the steps below to remove an ACL rule from an interface:
Note
active rules
You cannot delete active rules.
1. Select the interface from the "Interface" drop-down list.
2. Select the ACL rule in the "Remove Rule" drop-down list.
3. Click the "Remove" button. The corresponding entry is removed in the table.
