Siemens SIMATIC NET SCALANCE W780 Series User Manual

Description
2.8 Power over Ethernet (PoE)
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 08/2018, C79000-G8976-C267-13
39
Table 2- 3 Fitting connectors
PIN
Color of the
wire
CAT5
Color of the
wire
CAT6a
Use
Power over
unused wires
(10/100 Mbps
only)
Phantom power
1
Yellow
Green/white
Data
Data/power
2
Orange
Green
Data
Data/power
3 White Orange/white Data Data/power
6
Blue
Orange
Data
Data/power
4
Blue
Power
unused at 10/100 Mbps
5
Blue/white
Power
unused at 10/100 Mbps
7
Brown/white
Power
unused at 10/100 Mbps
8
Brown
Power
unused at 10/100 Mbps
LEDs for PoE on the SCALANCE W700 device
When the SCALANCE W700 device is supplied by PoE, the green "PoE" LED is lit on the
SCALANCE W700 device.

Siemens SIMATIC NET SCALANCE W780 Series Specifications

General

IP Rating	IP30
Product Type	Wireless Access Point
Frequency Bands	2.4 GHz, 5 GHz
Wireless Standard	IEEE 802.11a/b/g/n/ac
Data Rate	Up to 1.3 Gbps
Operating Temperature	-20°C to +60°C
Power Supply	24 V DC
Mounting Type	DIN rail, wall
Security	Firewall
Management	Web-based, SNMP, CLI
Weight	0.6 kg
