4.7 Response to errors
PN/BACnet LINK
Operating Instructions, 10/2017, A5E39895543-AA
43
4.7
Response to errors
Diagnostic resource
The device provides various tools to isolate the cause. These tools are listed below:
Diagnostic resource
Description
Examples of possible causes
of error
LED display The PN/BACnet LINK signals its state with the
LEDs on the front of the housing. The meaning
of the LEDs is described in section Operating
state of the PN/BACnet LINK / PROFINET
diagnostics (Page 77).
• Device fault
• Configuration error
• Network error:
SIMATIC diagnostics Information on the events that trigger a diag-
nostic message is available in the section
Events that trigger a diagnostic message
(Page 81). This section also includes a de-
tailed description of the error that triggers the
diagnostic message and possible measures.
• Fault in startup of firm-
ware
• Configuration error
• Network error:
BACnet status bit
OUT_OF_SERVICE
See section Data exchange between controller
and PN/BACnet LINK (Page 32)
• Configuration error
• Network error:
• Error in the control pro-
gram
BACnet system state See section Data exchange between controller
and PN/BACnet LINK (Page 32)
• Configuration error
• Network error:
• Error in the control pro-
gram
Below you will find a list of possible error situations and the corresponding response of the
PN/BACnet LINK.
Configuration error
During configuration, defective inputs and parameters are largely detected and reported
through compilation of the TIA Portal project. If the configuration does not correspond to the
associated system, error situations arise such as configuration errors (see following section).
Configuration error
If there is a configuration error, the configuration does not match the corresponding system,
or the system configuration changes in runtime. For example, BACnet objects are no longer
accessible or devices have been removed. The PN/BACnet LINK supports locating the
cause of the error as follows:
● If a configured BACnet object does not exist, the PN/BACnet LINK runs SIMATIC
diagnostics and sets the OUT_OF_SERVICE status bit for the S7 controller.
● If a configured BACnet device does not exist, the PN/BACnet LINK runs SIMATIC
diagnostics and sets the OUT_OF_SERVICE status bits for all objects of this device for
the S7 controller.
