Diagnostics
10.2 Diagnostic messages to the S7 controller
PN/BACnet LINK
Operating Instructions, 10/2017, A5E39895543-AA
81
10.2
Diagnostic messages to the S7 controller
10.2.1
Events that trigger a diagnostic message
Diagnostics
The PN/BACnet LINK sends diagnostic information to the S7 controller with the usual
PROFINET methods.
The following table provides an overview of
● Event text which is assigned to diagnostics
● Event for triggering diagnostics
● Possible remedy
Event text
Event for triggering
Possible remedy
BACnet application error -
Internal application error
Internal firmware error Restart
BACnet application error -
Internal timeout
Internal timeout in the firmware Restart
BACnet application error -
Error code: {1:x}
Error code = 0x80:
Ethernet configuration faulty
Correction of Ethernet configura-
tion
Error code = 0x81:
Initialization of BACnet server
failed
Correction of configuration or
Restart
Error code = 0x82:
Client initialization failed
Correction of configuration or
Restart
Foreign device registration
failed
Defective configuration for foreign
device registration
or
BBMD cannot be accessed
Correction of the configuration for
foreign device registration
or
Check whether BBMD is available
BACnet/IP interface failure The Ethernet connection on the
BACnet interface has failed.
Checking the Ethernet connection
on the BACnet interface
BACnet device cannot be
accessed - instance {1:d}:
Error while accessing the
device
A BACnet device is not accessi-
ble, incorrectly configured or has
failed
Checking the configuration for the
devices and of the BACnet connec-
tion and the BACnet device in
question
