Technical specifications
12.2 Dimension drawing
PN/BACnet LINK
Operating Instructions, 10/2017, A5E39895543-AA
89
Article number
6BK1621-0AA00-0AA0
Connection method
Design of electrical connection
Screw connection
Dimensions
Width
70 mm
Height
112 mm
Depth
75 mm
Weights
Weight
210 g
12.2
Dimension drawing
Dimension drawing of PN/BACnet LINK
Figure 12-1 Dimension drawing PN/BACnet LINK
