Configuring / Programming
9.5 Configure BACnet client
PN/BACnet LINK
70 Operating Instructions, 10/2017, A5E39895543-AA
3. Use the check boxes ① to specify the device objects to be transferred. The hierarchy
arrow
② indicates that I/O objects are contained in the BACnet device. By clicking on the
arrow, you can display the assigned I/O objects and select or deselect individual I/O
objects.
Note
Only object types supported by the device (BI, B
O, AI and AO) are imported.
4. To select the selected device objects or I/O objects, click the "Add selected objects"
button
③. The imported BACnet devices are now automatically transferred to the
configuration of the PN/BACnet LINK active in the project.
5. If needed, you can subsequently edit the I/O object references of the imported device
objects. See Creating object references manually (Page 72).
