Configuring / Programming
9.7 Programming
PN/BACnet LINK
76 Operating Instructions, 10/2017, A5E39895543-AA
Name diagram of the created PLC tags
Module/
Submodule
IO data
Name diagram
Data
type
S7 address
mnemonic
BACnet client
Prefix: <LinkName>.<ClientSubmoduleName>
ClientStatus <Prefix>.ClientStatus Bool %I< ByteAdr >.0
ClientControl
<Prefix>.ClientControl
Bool
%Q< ByteAdr >.0
BACnet server
Prefix:
<LinkName>.<ServerSubmoduleName>
ServerStatus
< Prefix >.ServerStatus
Byte
%IB< ByteAdr >
ServerControl
< Prefix >.ServerControl
Byte
%QB< ByteAdr >
Binary input
< Prefix >.<IOObjectName>
Bool
%Q< ByteAdr >.0
< Prefix >.<IOObjectName>.OUT_OF_SERVICE
Bool
%Q< ByteAdr >.7
Binary output
< Prefix >.<IOObjectName>
Bool
%I< ByteAdr >.0
< Prefix >.<IOObjectName>.OUT_OF_SERVICE
Bool
%Q< ByteAdr >.7
Analog input
< Prefix >.<IOObjectName>
Real
%QD< ByteAdr >
< Prefix >.<IOObjectName>.OUT_OF_SERVICE
Bool
%Q< ByteAdr >.7
Analog output
< Prefix >.<IOObjectName>
Real
%ID< ByteAdr >
< Prefix >.<IOObjectName>.OUT_OF_SERVICE
Bool
%Q< ByteAdr >.7
BACnet device
Prefix: <LinkName>.<BACnetDeviceModuleName>
Binary input
< Prefix >.<IOObjectRefName>
Bool
%I< ByteAdr >.0
< Prefix >.<IOObjectRefName >.IN_ALARM
Bool
%I< ByteAdr >.4
< Prefix >.<IOObjectRefName >.FAULT
Bool
%I< ByteAdr >.5
< Prefix >.<IOObjectRefName >.OVERRIDDEN
Bool
%I< ByteAdr >.6
< Prefix >.<IOObjectRefName >.OUT_OF_SERVICE
Bool
%I< ByteAdr >.7
Binary output
<
Prefix >.<IOObjectRefName > Bool %Q< ByteAdr >.0
< Prefix >.<IOObjectRefName >.IN_ALARM
Bool
%I< ByteAdr >.4
< Prefix >.<IOObjectRefName >.FAULT
Bool
%I< ByteAdr >.5
< Prefix >.<IOObjectRefName >.OVERRIDDEN
Bool
%I< ByteAdr >.6
< Prefix >.<IOObjectRefName >.OUT_OF_SERVICE
Bool
%I< ByteAdr >.7
Analog input
< Prefix >.<IOObjectRefName >
Real
%ID< ByteAdr >
< Prefix >.<IOObjectRefName >.IN_ALARM Bool %I< ByteAdr >.4
< Prefix >.<IOObjectRefName >.FAULT
Bool
%I< ByteAdr >.5
< Prefix >.<IOObjectRefName >.OVERRIDDEN
Bool
%I< ByteAdr >.6
< Prefix >.<IOObjectRefName >.OUT_OF_SERVICE
Bool
%I< ByteAdr >.7
Analog output
< Prefix >.<IOObjectRefName >
Real
%QD< ByteAdr >
< Prefix >.<IOObjectRefName >.IN_ALARM
Bool
%I< ByteAdr >.4
< Prefix >.<IOObjectRefName >.FAULT
Bool
%I< ByteAdr >.5
< Prefix >.<IOObjectRefName >.OVERRIDDEN
Bool
%I< ByteAdr >.6
< Prefix >.<IOObjectRefName >.OUT_OF_SERVICE
Bool
%I< ByteAdr >.7
I/Q: Input/output bit address
IB/QB: Input/out
put byte address
ID/QD: Input/output double word address
