Programming via SIMATIC controller
8.5 Programming Ident blocks
SIMATIC RF650R/RF680R/RF685R
122 Configuration Manual, 03/2018, C79000-G8976-C386-06
Table 8- 5 Explanation of the "Reader_Status" block
Parameter
Data type
Default values
Description
ATTRIBUTE Byte B#16#81 Identifier of the status mode "0x89"
Note: The default value is not valid for
RF680R/RF685R and needs to be
adapted.
IDENT_DATA Any / Variant 0 Event values depending on attributes
Note:
For Variant, an "Array_of_Byte" with a
variable length and the existing status
UDTs can be created. For Any, other
data types/UDTs can also be created.
Results
Table 8- 6 ATTRIBUTE "0x89" ("IID_READER_STATUS_89_RF68xR" data type)
Name
Type
Comment
status_info
BYTE
SLG-Status mode(Subcommand)
hardware_version
BYTE
Version of hardware
firmware_version
ARRAY[1..4] of
CHAR
Version of firmware
config ID
DWORD
Unix timestamp
inventory_status
WORD
0=inventory not active;1=inventory active;2=presence
mode active
sum of filtered tags
WORD
All filtered Tags
filtered_smoothing
WORD
Filtered Tags trough Smoothing
filtered_blacklist
WORD
Filtered Tags trough Blacklist
filtered data-filter
WORD
Filtered Tags trough Data-Filter
filtered RSSI thresold
WORD
Filtered Tags trough RSSI Threshold
filtered RSSI delta
WORD
Filtered Tags trough RSSI Delta
