Page #331 background image
Appendix
A.3 Command and acknowledgement frames
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
331
A.3.5
PHYSICAL-WRITE
Writes data to a transponder by specifying the physical start address, the memory bank
(UHF) and length.
Table A- 11 Command
Byte
0, 1 2, 3 4 5 6, 7 8 9 10 11 12
Mean-
ing
DBL SN CC CI TDB DBN_H DBN_L DBL -- SOURC
E
Value
-- -- 'q' 'U' -- 0 -- -- 0 0
Byte
13 14, 15 16, 17 18 ... 21 22, 23 24, 25 26 27 ... 88 89 ... 239
Mean-
ing
BANK ADRESS LENGTH PSWD -- -- IDLENG
TH
EPC-ID DATA
Value
xx
xx
xx
xx
0
0
xx
xx
--
Table A- 12 Reply
Byte
0, 1
2, 3
4
5
6, 7
8
9
10
Mean-
ing
DBL SN CC STATUS TDB DBN_H DBN_L DBL
Value
--
--
'q'
xx
1
--
--
--
Table A- 13 Description of the bytes
Byte
Description
12
Reserved (value = 0)
13 Memory bank on the transponder:
• 0x00 = RESERVED
• 0x01 = EPC
• 0x02 = TID
• 0x03 = USER
14, 15 Physical start address on the transponder:
• 0 ... 0xFFFF
16, 17
Number of bytes to be written
18 ... 21 Password for transponder access:
• 0x00 = no password
26 Length of the EPC ID:
• 0x00 = not addressed
27 ... 88
Buffer for up to 62 bytes EPC-ID
89 ... 239
Data that exceeds 239 bytes is transferred in several blocks.
