A.3 Command and acknowledgement frames
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
333
A.3.7
KILL-TAG
The transponder is permanently deactivated.
Table A- 17 Command
Byte
0, 1 2, 3 4 5 6, 7 8 9 10 11
Mean-
ing
DBL SN CC CI TDB DBN_H DBN_L DBL --
Value
78 -- 'j' 'U' 1 0 1 -- 0
Byte
12
13
14, 15
16, 17
18 ... 21
22, 23
24, 25
26
27 ... 88
Mean-
ing
SOURCE -- -- -- PSWD -- -- IDLENGT
H
EPC-ID
Value
0
0
0
0
0
0
0
--
--
Table A- 18 Reply
Byte
0, 1
2, 3
4
5
6, 7
8
9
10
Meaning
DBL
SN
CC
STATUS
TDB
DBN_H
DBN_L
DBL
Value
0
--
'j'
xx
1
--
1
0
Table A- 19 Description of the bytes
Byte
Description
12
Reserved (value = 0)
18, 19 Password for transponder access:
• 0x00 = no password
26 Length of the EPC ID:
• 0x00 = not addressed
27 ... 88
Buffer for up to 62 bytes EPC-ID

Siemens SIMATIC RF650R Specifications

General

Type	RFID Reader
Frequency band	UHF
Protection class	IP65
Power supply	24 V DC
Frequency Range	865 to 868 MHz (EU), 902 to 928 MHz (US)
RFID standard	ISO 18000-6C
Interfaces	Ethernet, RS232
Weight	1.2 kg
Read Range	Up to 8 m (depending on transponder and antenna)
Operating Temperature	-25 to +55 °C
