Page #141 background image
Programming via SIMATIC controller
8.6 Programming the Ident profile
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
141
Parameter
Data type
Default val-
ue
Description
EXT_UHF STRUCT -- Structure for additional parameters (RF680R/RF685R
only)
LEN_ID
BYTE
B#16#0
Length of the valid data in the "EPCID_UID" field.
MEM_BANK BYTE B#16#3 Memory bank on the transponder
• 0x00 = RESERVED
• 0x01 = EPC
• 0x02 = TID
• 0x03 = USER
PSWD DWORD DW#16#0 Password for transponder access
0x00 ≙ no password
EDIT_BLACKLIST_MODE BYTE B#16#0 Mode
• 0x00 = add EPC-ID
• 0x01 = add all "Observed" transponders
• 0x02 = delete EPC-ID
• 0x03 = delete all
INVENTORY_DURATION WORD W#16#0 Duration
Period of time or number of inventories or number of
"Observed" events
Example:
• 0x00 ≙ no inventory
• 0x01 ≙ one inventory
INVENTORY_DUR_UNIT WORD W#16#0 Unit for "DURATION"
• 0x00 = time [ms]
• 0x01 = inventories
• 0x02 = number of "Observed" events
LOCK-TAG-
BANK_ACTION
WORD W#16#0 Lock-Action (see "EPC Specification")
LOCK-TAG-BANK_MASK
WORD
W#16#0
Lock-Mask (see "EPC Specification")
