Programming via Rockwell controller
9.5 Programming add-on instructions
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
165
Table 9- 5 Explanation of the "Reader_Status" block
Parameter
Data type
Default values
Description
ATTRIBUTE SINT B#16#81 Identifier of the status mode "0x89"
Note: The default value is not valid for
RF680R/RF685R and needs to be
adapted.
IDENT_DATA SINT[10] 0 Event values depending on attributes
Note.
When necessary a byte/array of any
size can be transferred to this parame-
ter. Note that the array must be ≥ 10
bytes long (e.g. "SINT[12400]").
Results
Table 9- 6 ATTRIBUTE "0x89" ("IID_READER_STATUS_89_RF68xR" data type)
Name
Type
Comment
status_info
BYTE
SLG-Status mode(Subcommand)
hardware_version
BYTE
Version of hardware
firmware_version
ARRAY[1..4] of
CHAR
Version of firmware
config ID
DWORD
Unix timestamp
inventory_status
WORD
0=inventory not active;1=inventory active;2=presence
mode active
sum of filtered tags
WORD
All filtered Tags
filtered_smoothing
WORD
Filtered Tags trough Smoothing
filtered_blacklist
WORD
Filtered Tags trough Blacklist
filtered data-filter
WORD
Filtered Tags trough Data-Filter
filtered RSSI thresold
WORD
Filtered Tags trough RSSI Threshold
filtered RSSI delta
WORD
Filtered Tags trough RSSI Delta
