Programming via XML interface
10.2 Demo application
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
189
Figure 10-2 User interface of the demo application
The menu bar contains all available commands. These are grouped together in the relevant
menus. Each individual command can be selected from the menu tree.
Reader XML commands for connecting to the reader, disconnecting from the
reader and for selecting readers.
Connection XML commands with which you can control the connection between the
user application and readers.
Settings XML commands with which you can control the configuration of the
Tag XML commands with which you can control processing of the tran-
Extras XML command for resetting the Log window and for parameter assign-
ment and reading out log files
Information on the RFID reader XML demo
Using the menu command "Extras" > "SaveTagEventReports" you can save acquired
transponder data on your PC as a *.csv file or in an SQL database.
