Siemens SIMATIC RF650R

Programming via XML interface
10.3 XML commands
SIMATIC RF650R/RF680R/RF685R
216 Configuration Manual, 03/2018, C79000-G8976-C386-06
Command
<frame>
<cmd>
<id> value_id </id>
<resetReader>
<resetType> value_resetType </resetType> // opt
</resetReader>
</cmd>
</frame>
// opt → Optional: Line can be omitted.
Reply
<frame>
<reply>
<id> value_id </id>
<resultCode> 0 </resultCode>
<resetReader/>
</reply>
</frame>
The error codes for negative replies ("resultCode" ≠ 0) are described in the section "Negative
XML replies (Page 263)".
Parameter
Parameter
Type
Values
Description
value_id Decimal value
0...9
0...4294967295 Unique command identifier
resetType Fixed values Reset2Factory
Reboot
Optional
Type of reset
• Reset2Factory:
Reset to the factory settings and
delete the stored configuration.
• Reboot:
Hardware reader reset without de-
leting the stored configuration. After
the restart, communication must be
re-established.
The default is "Reboot".
